SymLine FLEX: The flexible waste disposal system for HPLC workstations

Collect liquid waste safely! With the most flexible collecting system which fits snugly into your laboratory facilities!

Simple, non-destrictive installation
Table or wall mounting possible.
Do-It-Yourself modular system
The system is designed for its suitability for your workplace. A minimum of components – many applications!
Can be flexibly integrated at any time
You can react quickly to any changes in your laboratory – whether it concerns additional workplaces or a reinstallation at another place: the system can be made to fit!
Central collection point for solvent waste
No obstruction due to containers standing in the working area. Liquids are safely collected, at one central point.
Anti-static and resistant to solvents
Electrically conductive plastic ensures for secure grounding/earthing, to avoid danger of ignition.

The modular system adapts to your HPLC workstations

You only need a single waste canister - with no waste canisters in the work area to get in the way. Extend or shorten the pipe system as required - all pipe elements are compatible and can be combined with each other.

Perfect integration - without structural replacement! The modular system adapts to your HPLC workstation!

Table or wall mounting: choose from various mounting options.

Magnetic: The system adheres to metal surfaces without any changes to the subsurface!

What is SymLine?

SymLine is the intelligent, modular collection system for liquid waste. It integrates perfectly into your laboratory equipment. It was specially developed for the requirements in the analytical laboratory.

The principle: Protection against escaping vapours and only one central collection point for liquid waste. Without annoying containers in the work area.

Discover the whole system! Click here for the SymLine website!

Go to the SymLine Website

SymLine is a registered trademark of SCAT Europe GmbH.

Catalogue chapter

The 17-page SymLine FLEX chapter from the SymLine Chemical Waste Systemes system catalogue. Everything you need to know summarised for you:

PDF Download

Matching products

SymLine FLEX - Starter Set, Standard

Product no.: 106692

SymLine FLEX - Starter Set, Standard, consisting of: - 1x 106688 (Basic 32 pipe), - 1x 106423 (Blind plug for 32 pipe), - 1x 106568 (SymLine FlexTube, Length 1000 mm - flexibly adaptable), - 1x 106475 (Shut-off, angled), - 1x 490336 (Exhaust filter M, V3.0, economy package), - 1x 306482 (Safety Waste Cap, S60/61, GL25 (m), connector for exhaust filter, PE-HD electrostatic conductive), - 2x 108042 (Canister 10 L, S60/61, PE-HD electrostatic conductive, with floater), - 1x 117985 (Collecting tray with base insert), - 1x 108176 (Grounding cable)

US$2,274.43*

SymLine FLEX - Starter Set, Premium

Product no.: 106694

SymLine FLEX - Starter Set, Premium, consisting of: - 1x 106688 (Basic 32 pipe), - 1x 106423 (Blind plug for 32 pipe), - 1x 106568 (SymLine FlexTube, Length 1000 mm - flexibly adaptable), - 1x 106475 (Shut-off, angled), - 1x 490336 (Exhaust filter M, V3.0, economy package), - 1x 107624 (Offset adapter 90° for exhaust filter), - 1x 106480 (Safety Waste Cap, S60/61, electronic level control, GL25(m), connector for exhaust filter, PE-HD electrostatic conductive), - 2x 107953 (Canister 10 L, S60/61, PE-HD electrostatic conductive), - 1x 117985 (Collecting tray with base insert), - 1x 108176 (Grounding cable), - 1 x 108050 (Signal cable for electronic level control, length = 3 m), - 1 x 108087 (Signal Box T1 - EU)

US$2,891.90*

SymLine FLEX - Extension 1

Product no.: 106690

SymLine FLEX - Extension - 1 x sealing ring PTFE-EL - 1 x knurled nut - Length = 600 mm - tensile strength (Rm) = 400 N, tightening torque = 10 - 15 Nm - PE-HD electrostatic conductive

US$199.60*

SymLine FLEX - Table mount

Product no.: 106691

SymLine FLEX - Table mount for piping system 32 mm (OD) - adjustable height

US$143.71*

SymLine FLEX - Extension 2

Product no.: 106689

SymLine FLEX - Extension - 1x GL45 (m) - 1 x sealing ring PTFE-EL - 1 x knurled nut - Length = 600 mm - tensile strength (Rm) = 400 N, tightening torque = 10 - 15 Nm - PE-HD electrostatic conductive

US$269.69*

SymLine FLEX- Basic 32 pipe, GL45 + GL25

Product no.: 106688

SymLine FLEX - Basic 32 pipe - 1x GL45 (m) - 1x GL25 (m) - 1 x sealing ring PTFE-EL - 1 x knurled nut - Length = 310 mm - tensile strength (Rm) = 400 N, tightening torque = 10 - 15 Nm - PE-HD electrostatic conductive

US$387.08*

Grounding for FlexTubes, ID 5mm, 3m

Product no.: 108289

Grounding cable - 1x clamp - 1x ring connector ID 5 mm - length = 3 m

US$56.16*

SymLine FLEX extension 1200 mm

Product no.: 106700

SymLine FLEX - Extension - 1 x sealing ring PTFE-EL - 1 x knurled nut - Length = 1200 mm - tensile strength (Rm) = 400 N, tightening torque = 10 - 15 Nm - PE-HD electrostatic conductive

US$284.22*

SymLine FLEX - Extension 4

Product no.: 106732

SymLine FLEX - Extension - 1x GL45 (m) - 1 x sealing ring PTFE-EL - 1 x knurled nut - Length = 1200 mm - tensile strength (Rm) = 400 N, tightening torque = 10 - 15 Nm - PE-HD electrostatic conductive

US$354.32*
