SymLine FLEX- Basic 32 pipe, GL45 + GL25

Skip image gallery

US$387.08*

Content: 1
Information on prices, delivery- and payment-terms
Product number: 106688

Delivery Time: 7-10 days

We make your Lab a safer Place!
The SCAT SymLine FLEX Basic 32 mm pipe forms the compact interface between GL45, GL25 and the 32 mm pipe system. The electrostatically conductive PE-HD design with sealing ring and knurled nut enables a tight, tensile-resistant connection. It allows HPLC waste to be routed flexibly and systematically into central collection systems.

Product information "SymLine FLEX- Basic 32 pipe, GL45 + GL25"

SymLine FLEX -  Basic 32 pipe

- 1x GL45 (m)

- 1x GL25 (m)

- 1 x sealing ring PTFE-EL

- 1 x knurled nut

- Length = 310 mm

-  tensile strength (Rm) = 400 N, tightening torque = 10 - 15 Nm

- PE-HD electrostatic conductive

Specifications
Main material: HDPE-el
